Needle Punched Polyester 100g Non Woven Geotextile Fabric

Needle Punched Polyester 100g Non Woven Geotextile Fabric

  • Needle Punched Polyester 100g Non Woven Geotextile Fabric
  • Needle Punched Polyester 100g Non Woven Geotextile Fabric
  • Needle Punched Polyester 100g Non Woven Geotextile Fabric
Needle Punched Polyester 100g Non Woven Geotextile Fabric
Product Details:
Place of Origin: China
Brand Name: Hengquan
Certification: ISO 9001
Model Number: TGSG15,TGSG20,TGSG25,TGSG30,TGSG35,TGSG40,TGSG45,TGSG50
Payment & Shipping Terms:
Minimum Order Quantity: 5000m2
Price: 0.25usd/㎡
Packaging Details: packing belt
Delivery Time: 5-8 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 40000 squre meters per week
Contact Now
Detailed Product Description
Thickness: 0.9-20.0mm Length: 50-100m
Width: 1-7m Package: PP Woven Bags
Color: White, Black, Yellow, Etc Applications : Landfill
Raw Material: PP(polypropylene) PET (polyester) Weight: 100-1000g/sqm
After-sale Service: Online Technical Support, Onsite Training, Onsite Inspection Design Style: Industrial
High Light:

100g non woven geotextile fabric

,

polyester non woven geotextile fabric

,

non woven geotextile fabric needle punched

Black Non Woven Geotextile Needle Punched Polyester Geotextile

Thanks to thermal process, more strength and less elongation is achieved with the same weight.Requires smaller storage area.Can be manufactured up to a width of 6 meters, leading to less loss of material.Both white and tinted varieties of ge0textile are manufactured from 100% pure yarn. No recycled material is used.Products can be manufactured with surface weight ranging from 50 gr/m2 to 1000 gr/m2.



Hot Selling White Or Black Non Woven Geotextile Needle Punched Polyester Geotextile

The nonwoven fabric can be used in almost any stabilization,separation or cushioning application,and they are most commonly used in areas that also require filatration.The non woven design of the material provides a higherrate of flow through,making it easier for water to pass through the material.Some commen uses of the material includes the following:

1. Road stabilization applications

2. Roofs

3. Civil applications

4. Railway work

5. Landfill lining

6. Trenches

7. Dams

8. Fitration under rip rap and rocks

9. Environmental applications

Gram weight
Thickness(mm)
Breaking strength(kn/m)
CBR burst strength(KN)
Elongation at break(%)
Tear Strength (KN)
Sieve size O99(O35)mm
100
0.9
2.5
0.3
25-100
0.08
0.07-2.0
150
1.3
4.5
0.6
25-100
0.12
0.07-2.0
200
1.7
6.5
0.9
25-100
0.16
0.07-2.0
250
2.1
8.0
1.2
25-100
0.20
0.07-2.0
300
2.4
9.5
1.5
25-100
0.24
0.07-2.0
350
2.7
11.0
1.8
25-100
0.28
0.07-2.0
400
3.0
12.5
2.1
25-100
0.33
0.07-2.0
450
3.3
14.0
2.4
25-100
0.38
0.07-2.0
500
3.6
16.0
2.7
25-100
0.42
0.07-2.0
600
4.1
19.0
3.2
25-100
0.46
0.07-2.0
800
5.0
25.0
4.0
25-100
0.60
0.07-2.0





Needle Punched Polyester 100g Non Woven Geotextile Fabric 0Needle Punched Polyester 100g Non Woven Geotextile Fabric 1Needle Punched Polyester 100g Non Woven Geotextile Fabric 2Needle Punched Polyester 100g Non Woven Geotextile Fabric 3Needle Punched Polyester 100g Non Woven Geotextile Fabric 4Needle Punched Polyester 100g Non Woven Geotextile Fabric 5
