Name: Pp Non Woven Geotextile Fabric 0.9mm To 5.0mm Thick
Brand: Hengquan
SKU: TGSG15,TGSG20,TGSG25,TGSG30,TGSG35,TGSG40,TGSG45,TGSG50
Price: 0.25 USD
Availability: InStock
Rating: 4.6 (195 reviews)

Home Products Non Woven Geotextile Fabric

Pp Non Woven Geotextile Fabric 0.9mm To 5.0mm Thick

Product Details:

Place of Origin:	China
Brand Name:	Hengquan
Certification:	ISO 9001
Model Number:	TGSG15,TGSG20,TGSG25,TGSG30,TGSG35,TGSG40,TGSG45,TGSG50

Payment & Shipping Terms:

Minimum Order Quantity:	5000m2
Price:	0.25usd/㎡
Packaging Details:	packing belt
Delivery Time:	5-8 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	40000 squre meters per week

Contact Now

Detailed Product Description

Product Name:	PP Needlepunched Nonwoven Geotextile	Thickness:	0.9mm TO 5.0mm
Length:	50-100m	Supply Ability:	10000 Square Meter/Square Meters Per Day
Package:	PP Woven Bags	Color:	Black, Gray, Green
Applications :	Soft Foundation Reinforcement	Certificate:	Iso9001
High Light:	0.9mm non woven geotextile fabric , pp non woven geotextile fabric , 5.0mm nonwoven geotextile fabric

polyester pet filament pp non-woven non woven nonwoven geo textile cloth roll geotextile

Non-woven geotextile

Geotextiles are permeable fabrics which, when used in association with soil, have the ability to separate, filter, reinforce, protect, or drain. Typically made from polypropylene or polyester, geotextile fabrics come in three basic forms: woven (resembling mail bag sacking), needle punched (resembling felt), or heat bonded (resembling ironed felt).

Geotextile composites have been introduced and products such as geogrids and meshes have been developed. Geotextiles are able to withstand many things, are durable, and are able to soften a fall if someone falls down. Overall, these materials are referred to as geosynthetics and each configuration—geonets, geosynthetic clay liners, geogrids, geotextile tubes, and others—can yield benefits in geotechnical and environmental engineering design.

Service	Trade assurance
Certification	NTPEP, SGS, ISO
Material	100% New PP material
Weight	From 260-1300mm, as the customers requirement
Length,Color	As the customer's requirement
Weave	9x9, 10x10,11x11,12x12, 13x 13, 14x14,or as your requirement
Denier	450D to 1500D
Weights/m²	30g to 200g, as your requirment
sample	Avaliable
Certification	NTPEP, SGS,ISO9000, ISO14000, ISO 18000, SGS, FSC,WQA
Usage	rice, flour, sugar, salt, animal feed, asbestos, fertilizer, sand, cement Construction,and so on.
Packing	500pcs/bundle(bale),1000pcs/bundle(bale) or can be customized
Delivery Time	10-30 days after place an order or negotiation
Minium Order	20 feet container
Trade Term	FOB Qingdao, or as your order
Payment Term	T/T L/C
Treat	UV treated or as the customers' requirement
Loading qty	12tons/20’container, 26tons/40’hq

Features 01

Non-woven geotextile is a non-Woven geotextile,which is a multifunctional fabric with a similar appearance. Non-woven geotextiles have different strengths and thicknesses.

Features 02
The isolation of the railway dregs and the roadbed, roadbed and the soft base,surface of the airdrome and parking lot and the groundsill, different dam materials.

Advantages· Excellent chemical compatibility.

· Long-term performance in strength and durability.

· Extends road and railway life.

· Cost-effective environmental alternative to traditional construction materials.

· Prevents banks from soil erosion.

· Easy to install.

High tensile strength and low elongation provides dimensional stability

Requires less aggregate, reducing the overall thickness of the road
Increases performance life of the road
Withstands tough construction loading
Resistant to ultraviolet degradation
Resistant to biological clogging, making it ideal for leachate collection systems and filtration beneath hard armor system
Ease of installation reduces time and labor costs

Product Application

Water conservancy project and hydropower projects.

Road paving, railway.

Airport and port.

River band protection and tunnel.

Environmental protection, etc.

Features

UV resistant.

High temperature resistance to up to 230℃ maintaining structure stability and original physical properties.

High flat drainage and vertical permeability.

High creep resistance.

Resistance of erosion of chemicals in soil as well as thecorrosion of gasoline and diesel etc.

High elongation under certain stress, thus able to adapt to uneven and irregular bases.

Product inventory:

Gram weight	Thickness(mm)	Breaking strength(kn/m)	CBR burst strength(KN)	Elongation at break(%	Tear Strength(KN)	Sieve size O99(O35)mm
100	0.9	2.5	0.3	25-100	0.08	0.07-2.0
150	1.3	4.5	0.6	25-100	0.12	0.07-2.0
200	1.7	6.5	0.9	25-100	0.16	0.07-2.0
250	2.1	8.0	1.2	25-100	0.20	0.07-2.0
300	2.4	9.5	1.5	25-100	0.24	0.07-2.0
350	2.7	11.0	1.8	25-100	0.28	0.07-2.0
400	3.0	12.5	2.1	25-100	0.33	0.07-2.0
450	3.3	14.0	2.4	25-100	0.38	0.07-2.0
500	3.6	16.0	2.7	25-100	0.42	0.07-2.0
600	4.1	19.0	3.2	25-100	0.46	0.07-2.0
800	5.0	25.0	4.0	25-100	0.60	0.07-2.
