Anping County Hengquan Metal Wire Mesh Products Co.,Ltd
geogrids, geotextiles, geocells, geomembrane, chain link fence , welded wire mesh panel, hexagonal wire netting
 |
| Place of Origin: | China |
| Brand Name: | Hengquan |
| Certification: | ISO 9001 |
| Model Number: | TGSG15,TGSG20,TGSG25,TGSG30,TGSG35,TGSG40,TGSG45,TGSG50 |
| Minimum Order Quantity: | 1000m2 |
|---|---|
| Price: | Deliberation |
| Packaging Details: | packing belt |
| Delivery Time: | 5-8 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 40000M2 per week |
| Type: | Geogrids | Width: | 3.9 Meters Or 5.9 Meters |
|---|---|---|---|
| Length: | 50 Meters | Color: | Black, Gray, Green |
| Tensile Strength: | TGSG 30-30KN | Mesh Hole: | 32*32mm |
| Used: | Prevent Soil Erosion | Material: | Polypropylene |
| Tensile Strength: | 25Kn/m--300Kn/m | Application: | Road Construction .mine Laneway,roadbed,Highway Road,Road Reinforcement,and Construction |
| High Light: | 30KN Biaxial Plastic Geogrid,3.9m Biaxial Plastic Geogrid,30KN Plastic Geogrid Mesh |
||
Apply In Mining, Tunnel Reinforcement Prevent Soil Erosion High Strength Polypropylene Biaxial Plastic Geogrid
Biaxial Plastic Geogrid Introduction
Biaxial geogrid is made of high molecular polymer after extruded and laminated and punched into regular mesh before longitudinal stretching.The material on the longitudinal and transverse has great tensile strength, this kind of structure in the soil can also provide a more effectively undertake the chain and the spread of the thought system, suitable for large area of permanent bearing foundation reinforcement.
Biaxial Plastic Geogrid Specification
| project | TGSG15-15 | TGSG20-20 | TGSG25-25 | TGSG30-30 | TGSG40-40 | TGSG45-45 | TGSG50-50 |
| Longitudinal tensile yield force KN/m | 15 | 20 | 25 | 30 | 40 | 45 | 50 |
| Transverse tensile yield force KN/m | 15 | 20 | 25 | 30 | 40 | 45 | 50 |
| Tensile Strength @2% Strain KN/m | 5 | 7 | 9 | 10.5 | 14 | 16 | 17.5 |
| Tensile Strength @5% Strain KN/m | 7 | 14 | 17 | 21 | 28 | 32 | 35 |
| Roll width | 3.95 or 5.95 meters | ||||||
| Roll Length | 50 meters | ||||||
Biaxial Plastic Geogrid Features
1.High tension resistance, high plane torsion resistance modulus, good creep resistance and stable chemical nature.
2.High mechanic damage resistance and durability and large friction factor with sandy stone.
3. Convenient construction, saving effort, shortening construction period and reducing maintenance cost.
4. Strengthen soil slopes to prevent soil erosion.
5. Can replace metal mesh, used in coal mine underground false roof network.
Biaxial Plastic Geogrid Function
1. It can be applied in all kinds of roads, railways, airports to enhance the roadbed.
2. It can be applied in a large car park and terminal freight yard, etc. to strengthen the foundations of a permanent load;
3. It can be applied in rail, road slope's protection;
4. It can be applied to enhance the culvert;
5. It can be applied as a secondary enhancement after the uniaxial geogrid soil enhancement, further enhancement to the soil; prevent soil erosion
