800g Non Woven Geotextile Polypropylene Fabric For Reinforcement

800g Non Woven Geotextile Polypropylene Fabric For Reinforcement

  • 800g Non Woven Geotextile Polypropylene Fabric For Reinforcement
  • 800g Non Woven Geotextile Polypropylene Fabric For Reinforcement
  • 800g Non Woven Geotextile Polypropylene Fabric For Reinforcement
800g Non Woven Geotextile Polypropylene Fabric For Reinforcement
Product Details:
Place of Origin: China
Brand Name: Hengquan
Certification: ISO 9001
Model Number: TGSG15,TGSG20,TGSG25,TGSG30,TGSG35,TGSG40,TGSG45,TGSG50
Payment & Shipping Terms:
Minimum Order Quantity: 5000m2
Price: 0.25usd/㎡
Packaging Details: packing belt
Delivery Time: 5-8 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 40000 squre meters per week
Contact Now
Detailed Product Description
Thickness: 0.9mm TO 5.0mm Length: 50-100m
Supply Ability: 10000 Square Meter/Square Meters Per Day Package: PP Woven Bags
Color: Black, Gray, Green Applications : Outdoor, Building Construction
Raw Material: PP/ PET (Polypropylene/Polyester) Weight: 100--800g/M2
High Light:

reinforcement non woven geotextile polypropylene fabric

,

800g non woven geotextile polypropylene fabric

,

800g non woven fabric geotextile

Polypropylene Woven Geotextile Fabric For Reinforcement

Description:
Made from PET(polyester) or PP(polypropylene) by nonwoven needle punched manufacturing, it has isolation, filtration, drainage,
reinforcement, protection and maintenance etc. fuction.
Specification:
(1). 80g/m2~1000g/m2
(2). 1m~8m in roll width, the length as client's request.
(3). Color: white , black , green or at your request
Property:
(1). Good flexibility, resistant to corrosion, resistant to acids and alkali, anti-oxidation
(2). Separation, filtration, drainage, reinforcement , protection and maintentance function.



High tensile strength and low elongation provides dimensional stability
Requires less aggregate, reducing the overall thickness of the road
Increases performance life of the road
Withstands tough construction loading
Resistant to ultraviolet degradation
Resistant to biological clogging, making it ideal for leachate collection systems and filtration beneath hard armor system
Ease of installation reduces time and labor costs



1. UV resistant.
2. High temperature resistance to up to 230℃ maintaining structure stability and original physical properties.
3. High flat drainage and vertical permeability.
4. High creep resistance.
5. Resistance of erosion of chemicals in soil as well as thecorrosion of gasoline and diesel etc.
6. High elongation under certain stress, thus able to adapt to uneven and irregular bases.

Gram weight
Thickness(mm)
Breaking strength(kn/m)
CBR burst strength(KN)
Elongation at break(%)
Tear Strength (KN)
Sieve size O99(O35)mm
100
0.9
2.5
0.3
25-100
0.08
0.07-2.0
150
1.3
4.5
0.6
25-100
0.12
0.07-2.0
200
1.7
6.5
0.9
25-100
0.16
0.07-2.0
250
2.1
8.0
1.2
25-100
0.20
0.07-2.0
300
2.4
9.5
1.5
25-100
0.24
0.07-2.0
350
2.7
11.0
1.8
25-100
0.28
0.07-2.0
400
3.0
12.5
2.1
25-100
0.33
0.07-2.0
450
3.3
14.0
2.4
25-100
0.38
0.07-2.0
500
3.6
16.0
2.7
25-100
0.42
0.07-2.0
600
4.1
19.0
3.2
25-100
0.46
0.07-2.0
800
5.0
25.0
4.0
25-100
0.60
0.07-2.0





800g Non Woven Geotextile Polypropylene Fabric For Reinforcement 0800g Non Woven Geotextile Polypropylene Fabric For Reinforcement 1800g Non Woven Geotextile Polypropylene Fabric For Reinforcement 2800g Non Woven Geotextile Polypropylene Fabric For Reinforcement 3800g Non Woven Geotextile Polypropylene Fabric For Reinforcement 4800g Non Woven Geotextile Polypropylene Fabric For Reinforcement 5800g Non Woven Geotextile Polypropylene Fabric For Reinforcement 6800g Non Woven Geotextile Polypropylene Fabric For Reinforcement 7
