Anping County Hengquan Metal Wire Mesh Products Co.,Ltd
geogrids, geotextiles, geocells, geomembrane, chain link fence , welded wire mesh panel, hexagonal wire netting
 |
| Place of Origin: | China |
| Brand Name: | Hengquan |
| Certification: | ISO 9001 |
| Model Number: | 100 - 800 G/㎡ |
| Minimum Order Quantity: | 1000m2 |
|---|---|
| Price: | Deliberation |
| Packaging Details: | packing belt |
| Delivery Time: | 5-8 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 40000M2 per week |
| Material: | Polyester Or PP | Geotextile Type: | Non-Woven Geotextiles |
|---|---|---|---|
| Supply Ability: | 50000 Square Meter Per Week | Weight: | 100-1000g/sqm |
| Fiber Type: | Staple Fiber | Usage: | Isolation, Protection, Filter And Drain |
| Package: | PP Woven Bags | Main Weight: | 200g,300g,400g,500g Etc. |
| High Light: | road reinforced non woven geotextile fabric,needle punch non woven geotextile fabric,non woven needle punch filter fabric |
||
High Strength Road Reinforced Polyester Needle Punched Nonwoven Geotextile
1. Non woven Geotextile Fabric Description
Material: Polyester(PET)
Weight / Mass: 100gsm ~ 800gsm
Width: 1m ~ 6m
Length: 50m or 100m/roll
Thickness: 0.9mm ~ 5.0mm
Temperature range: -60℃ ~ +60℃
Color: Black , white , grey, green
2. What is Geotextile
The meaning of geotextile:
Geotextile is a composite woven of high-strength fiber tows and non-woven fabrics. The process is to arrange the fiber bundles straight to give full play to the force of the yarn. The non-woven fabric is under it, and the warp-knitting technology wraps it up to consolidate the fiber tow non-woven fabric, which not only maintains the filtration of the non-woven fabric, but also has the strength of the woven fabric.
3. Non woven Geotextile Fabric Specification
| Gram weight | Thickness(mm) | Breaking strength(kn/m) | CBR burst strength(KN) | Elongation at break(% | Tear Strength(KN) | Sieve size O99(O35)mm |
| 100 | 0.9 | 2.5 | 0.3 | 25-100 | 0.08 | 0.07-2.0 |
| 150 | 1.3 | 4.5 | 0.6 | 25-100 | 0.12 | 0.07-2.0 |
| 200 | 1.7 | 6.5 | 0.9 | 25-100 | 0.16 | 0.07-2.0 |
| 250 | 2.1 | 8.0 | 1.2 | 25-100 | 0.20 | 0.07-2.0 |
| 300 | 2.4 | 9.5 | 1.5 | 25-100 | 0.24 | 0.07-2.0 |
| 350 | 2.7 | 11.0 | 1.8 | 25-100 | 0.28 | 0.07-2.0 |
| 400 | 3.0 | 12.5 | 2.1 | 25-100 | 0.33 | 0.07-2.0 |
| 450 | 3.3 | 14.0 | 2.4 | 25-100 | 0.38 | 0.07-2.0 |
| 500 | 3.6 | 16.0 | 2.7 | 25-100 | 0.42 | 0.07-2.0 |
| 600 | 4.1 | 19.0 | 3.2 | 25-100 | 0.46 | 0.07-2.0 |
| 800 | 5.0 | 25.0 | 4.0 | 25-100 | 0.60 | 0.07-2.0 |
4. The specific functions are as follows:
Geotextiles are widely used in geotechnical engineering such as water conservancy, electric power, mines, roads and railways:
l. Filter material for soil layer separation;
2. Drainage materials for reservoirs and mines beneficiation, and drainage materials for foundations of high-rise buildings;
3. Anti-scouring materials for river dams and slope protection.
5. Application
The use of geotextiles is widely used in geotechnical engineering such as water conservancy, electric power, mines, roads and railways:
1. Filter material for soil separation;
2. Drainage materials for reservoirs and mines beneficiation, and drainage materials for foundations of high-rise buildings;
3. Anti-scouring materials for river dams and slope protection;
4. Reinforcement materials for road foundations of railways, highways and airports, and reinforcement materials for road construction in swamp areas;
5. Anti-frost and anti-freeze insulation materials;
6. Anti-cracking material for asphalt pavement.
6. Quality Control
We have established a national-standard laboratory for in-house quality control and built a strict quality control system in all aspects from raw materials testing and production processes to final product quality testing.
Not only is stringent internal quality control carried out at OBOR, but regular testing and analyzing of our product performance is implemented by authoritative testing organizations in Europe and the United States.
7. How to place order
--> Contact us by email, whatsapp or phone.
--> Negotiate prices and details, get a low price with good quality
--> Pay for articles, to our bank acount in China.
--> We produce then send goods.
Welcome to consult.
Leo
Manager of Hengquan Company in China.
Phone/Whatsapp: 008615030705799
Address: Anping city, Hebei Province, China, 053200
Contact Person: Mrs. ruby
Tel: +86-13623182253
Fax: 86-318-7990083
