Anping County Hengquan Metal Wire Mesh Products Co.,Ltd
geogrids, geotextiles, geocells, geomembrane, chain link fence , welded wire mesh panel, hexagonal wire netting
 |
| Place of Origin: | China |
| Brand Name: | Hengquan |
| Certification: | ISO 9001 |
| Model Number: | 100 - 800 G/㎡ |
| Minimum Order Quantity: | 1000m2 |
|---|---|
| Price: | Deliberation |
| Packaging Details: | packing belt |
| Delivery Time: | 5-8 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 40000M2 per week |
| Material: | Polyester | Geotextile Type: | Non-Woven Geotextiles |
|---|---|---|---|
| Supply Ability: | 50000 Square Meter Per Week | Weight: | 100 - 800 Gsm |
| Feature: | High Tensile Strength | Fiber Type: | Staple Fiber |
| Application: | Road, Road Railway Construction | Package: | Bundle |
| Main Weight: | 200g,300g,400g,500g Etc. | ||
| High Light: | soil reinforcement non woven polyester geotextile,200g non woven polyester geotextile,non woven polyester geotextile 200g |
||
200g Stab-Resistant Reinforced Non Woven Polyester Geotextile For Soil Reinforcement
1. Non woven Geotextile Fabric Description
Material: Polyester(PET)
Weight / Mass: 100gsm ~ 800gsm
Width: 1m ~ 6m
Length: 50m or 100m/roll
Thickness: 0.9mm ~ 5.0mm
Temperature range: -60℃ ~ +60℃
Color: Black , white , grey, green
2. What is Geotextile
1. Geotextile material: synthetic fiber.
2. Geotextile is a permeable geosynthetic material made of synthetic fiber needles through punching or weaving. Geotextile is one of the new materials and geosynthetics, and the finished product is cloth-like. Geotextiles are divided into woven geotextiles and non-woven filament geotextiles. Due to the plastic fiber used, it can maintain sufficient strength and stretch even in a dry state;
3. The reason why geotextiles can prevent corrosion for a long time in soil or water with different pH levels is that there are gaps between the fibers, so they have good water permeability. Because the material of geotextiles is light, soft, and It is easy to transport, which greatly improves the construction efficiency and is very convenient to use.
3. Non woven Geotextile Fabric Specification
| Gram weight | Thickness(mm) | Breaking strength(kn/m) | CBR burst strength(KN) | Elongation at break(% | Tear Strength(KN) | Sieve size O99(O35)mm |
| 100 | 0.9 | 2.5 | 0.3 | 25-100 | 0.08 | 0.07-2.0 |
| 150 | 1.3 | 4.5 | 0.6 | 25-100 | 0.12 | 0.07-2.0 |
| 200 | 1.7 | 6.5 | 0.9 | 25-100 | 0.16 | 0.07-2.0 |
| 250 | 2.1 | 8.0 | 1.2 | 25-100 | 0.20 | 0.07-2.0 |
| 300 | 2.4 | 9.5 | 1.5 | 25-100 | 0.24 | 0.07-2.0 |
| 350 | 2.7 | 11.0 | 1.8 | 25-100 | 0.28 | 0.07-2.0 |
| 400 | 3.0 | 12.5 | 2.1 | 25-100 | 0.33 | 0.07-2.0 |
| 450 | 3.3 | 14.0 | 2.4 | 25-100 | 0.38 | 0.07-2.0 |
| 500 | 3.6 | 16.0 | 2.7 | 25-100 | 0.42 | 0.07-2.0 |
| 600 | 4.1 | 19.0 | 3.2 | 25-100 | 0.46 | 0.07-2.0 |
| 800 | 5.0 | 25.0 | 4.0 | 25-100 | 0.60 | 0.07-2.0 |
4. The specific functions are as follows:
Geotextiles are widely used in geotechnical engineering such as water conservancy, electric power, mines, roads and railways:
l. Filter material for soil layer separation;
2. Drainage materials for reservoirs and mines beneficiation, and drainage materials for foundations of high-rise buildings;
3. Anti-scouring materials for river dams and slope protection.
5. Quality Control
We have established a national-standard laboratory for in-house quality control and built a strict quality control system in all aspects from raw materials testing and production processes to final product quality testing.
Not only is stringent internal quality control carried out at OBOR, but regular testing and analyzing of our product performance is implemented by authoritative testing organizations in Europe and the United States.
6. How to place order
--> Contact us by email, whatsapp or phone.
--> Negotiate prices and details, get a low price with good quality
--> Pay for articles, to our bank acount in China.
--> We produce then send goods.
Welcome to consult.
Leo
Manager of Hengquan Company in China.
Phone/Whatsapp: 008615030705799
Address: Anping city, Hebei Province, China, 053200
Contact Person: Mrs. ruby
Tel: +86-13623182253
Fax: 86-318-7990083
