Name: Soil Reinforcement Customized 0.2mm Uniaxial Plastic Geogrid
Brand: Hengquan
SKU: TGDG35-300 KN
Price: 1.00 USD
Availability: InStock
Rating: 4.6 (181 reviews)

Home Products Uniaxial Plastic Geogrid

Soil Reinforcement Customized 0.2mm Uniaxial Plastic Geogrid

Product Details:

Place of Origin:	China
Brand Name:	Hengquan
Certification:	ISO 9001
Model Number:	TGDG35-300 KN

Payment & Shipping Terms:

Minimum Order Quantity:	1000m2
Price:	Deliberation
Packaging Details:	packing belt
Delivery Time:	5-8 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	40000M2 per week

Contact Now

Detailed Product Description

Brand Name:	HENG QUAN	Sample:	Free Of Charge
Package:	PP Woven Bags	Project Solution:	Online Technical Support
Supply Ability:	50000 Square Meters Per Week Geogrid	Thickness:	0.2mm-4mm
Tensile Strength:	35--260kN/m	Usage:	Road Railway Construction
Weight:	300gsm-600gsm	Width:	1m/2m/3m/4m/5m/6m
High Light:	0.2mm uniaxial plastic geogrid , customized uniaxial plastic geogrid , soil reinforcement uniaxial geogrid

Soil Reinforcement Geogrid For Sale Uniaxial Plastic Specialized Customized Grid

Uniaxial Plastic Geogrid Introduction

The unidirectional geogrid is a kind of high molecular polymer as the main raw material, adding certain anti-ultraviolet, anti-aging additives, after unidirectional stretching, the originally distributed chain-shaped molecules are re-orientated and arranged in a linear state. It is a high-strength geotechnical material that is pressed into a thin plate and punched with regular meshes, and then stretched longitudinally. . In this process, the polymer becomes a directional linear state and forms an oblong network integral structure with uniform distribution and high node strength.

Uniaxial Plastic Geogrid Specification

Properties	GG60PP	GG80PP	GG110PP	GG150PP	GG260PP	GG300PP
Tensile Strength (kN/m)	60	80	110	150	260	300
Elongation Ratio	≤10%	≤10%	≤10%	≤10%	≤10%	≤10%
Strength at 2% Elongation (≥kN/m)	17	26	32	45	94	105
Strength at 5% Elongation (≥kN/m)	35	48	64	90	185	195
Roll Length (m)	100	100	50	50	50	50
Roll Width (m)	1-3	1-3	1-3	1-3	1-3	1-3

Uniaxial Plastic Geogrid Feature

In this process, the polymer becomes a oriented linear state and forms an oblong network integral structure with uniform distribution and high node strength. This structure has quite high tensile strength and tensile modulus. The tensile strength reaches 100-200Mpa, which is close to the level of low-carbon steel. It is much better than traditional or existing reinforced materials, and has a high level beyond the international level. Early (elongation in 2%-5%) tensile strength and tensile modulus. It provides the soil with an ideal interlocking system for bearing and spreading forces. The product has high tensile strength (>150Mpa), adapts to various soils, and is a widely used reinforcement material.

Plastic Uniaxial Geogrid Fuction

What is the function of the one-way geogrid? The one-way grille is commonly used in northern areas. The two-way geogrid is mainly used in areas that have different requirements for the positive and negative increase limits of the geogrid in different regions and in different seasons, climate, orientation, natural disasters, and production environment. Especially when the two-way direction is negative increase limit, the two-way grid should be used to fill these amounts to play a filling role. Definition and principle of one-way geogrid A one-way geogrid is a three-dimensional geogrid used in the contaminated area of stone and gravel waters. The one-way grille is mainly aimed at the water environment of stone and crushed stone. The product quality is advanced, the structure is simple, and the construction is convenient. The one-way grid can appear as a green product in some cases, and is often used in urban environmental landscapes where the green area is large and the negative increase limit is relatively large. At the same time, the garden three-dimensional vehicle with one-way grille can also be used in special orientation (head or tail). Definition and principle of two-way geogrid Two-way geogrid is aimed at water pollution and overall pollution inside the stratum. The application of two-way grille is wider than one-way, and it must be adjusted according to the conditions after construction. The construction of two-way grids causes great natural and artificial pollution to the building and the surrounding water body, and the construction is cumbersome, and the flexibility of combination and design is not strong.

Uniaxial Plastic Geogrid Usage

1. Strengthen the roadbed, effectively distribute the diffusion load, improve the stability and bearing capacity of the roadbed, and extend the service life;

2. Able to withstand greater alternating loads;

3. Prevent roadbed deformation and cracking caused by loss of roadbed materials; unidirectional plastic geogrid.

4. Improve the self-supporting capacity of the filling behind the retaining wall, reduce the earth pressure of the retaining wall, save costs, extend the service life, and reduce maintenance costs;

5. The use of spray anchor concrete construction method for slope maintenance can not only save 30%-50% of the investment, but also shorten the construction period by more than twice;

6. Adding geogrids to the roadbed and surface of the highway can reduce deflection and rutting, delay the occurrence of cracks by 3-9 times, and the thickness of the structural layer can be reduced to 36%;

7. Suitable for all kinds of soil, no need to obtain materials from different places, saving time and effort;

8. The construction is simple and fast, which can greatly reduce the construction cost.

Construction method of one-way geogrid:

Construction method of one-way geogrid:

When used on roadbeds and pavements, the construction method is the same as the two-way geogrid. When used for reinforced soil retaining walls, the construction methods are as follows:

1. Set up the foundation and carry out construction according to the designed wall system.

2.When precast reinforced concrete panels are selected, they are generally supported on a precast concrete foundation with a thickness of 12-15 cm. The width is not more than 30cm, the thickness is not less than 20cm, and the buried depth is not less than 60cm to prevent the influence of frost heave of the foundation.

3. For laying of reinforcements, the main strength direction of the reinforcements should be perpendicular to the wall and fixed with pins. isD Feicheng Lianyi Engineering Plastics Co., Ltd.

4. The wall shall be filled with soil by mechanical filling, and the distance between the wheel and the reinforcement shall be kept at least 15 cm. After compaction, a layer of soil is about 20-15 cm thick. isD Feicheng Lianyi Engineering Plastics Co., Ltd.

5. During wall construction, geotextiles should be covered on the wall to prevent leakage of the fill.

Company introduction:

Hengquan company was established in 2013, has become one of the leading and professional manufacture of many kinds of Geosynthetics and wire mesh.
(such as:Geocell,Geotextile,Geomembrane, Geogrid,, ,Gabion box,Welded wire mesh panel) in the world market. We got quality control to make sure every product be in good quality, which can make sure that any bad products will not sent to clients.

We got customers from American, Canada, Russia,Gemany and over 20 countries and enjoy good reputation.
