Chicken Animal Barrier Fence Pp Geogrid 5.9m Width

Product Details:

Place of Origin:	Anping, China
Brand Name:	China
Certification:	ISO 9001
Model Number:	TGSG15-50

Payment & Shipping Terms:

Minimum Order Quantity:	1000 square meters
Price:	Negotiation
Packaging Details:	packing belt
Delivery Time:	5-8 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	40000M2 per week

Contact Now

Detailed Product Description

Material:	Polypropylene	Width:	3.9 Meters Or 5.9 Meters
Length:	50 Meters	Tensile Strength:	TGSG 25-25KN
Color:	Black/White	Feature:	High Tension Resistance
Applications:	Convenient To Construct	After-sale Service:	Graphic Design
Property:	Reinforcement	Raw Material:	Plastic PP
High Light:	animal barrier fence pp geogrid , chicken barrier fence pp geogrid , 5.9m width pp geogrid

Chicken Animal Barrier Fence Plastic Geogrids Polypropylene Net Prices Biaxial Geogrid Mesh

Anping County Hengquan Metal Wire Mesh Products Co.,Ltd established in 2013, has specialized in the production and marketing of geogrids, geotextiles, geocells, geomembrane, chain link, welded wire mesh panel, hexagonal wire netting. The company now has a staff of 150 and 18 sets of professional high-tech equipment for geosynthetics and wire mesh production.

Biaxial Plastic Geogrid Introduction

Bidirectional plastic geogrid is made of high molecular polymer through extrusion, forming plate, punching process and then longitudinal and transverse tension. The material has great tensile strength in both longitudinal and transverse directions. This kind of structure can also provide a more effective chain system for bearing and diffusing force in soil, which is suitable for foundation reinforcement with large area permanent bearing.

Biaxial Plastic Geogrid Specification

project	TGSG15-15	TGSG20-20	TGSG25-25	TGSG30-30	TGSG40-40	TGSG45-45	TGSG50-50
Longitudinal tensile yield force KN/m	15	20	25	30	40	45	50
Transverse tensile yield force KN/m	15	20	25	30	40	45	50
Tensile Strength @2% Strain KN/m	5	7	9	10.5	14	16	17.5
Tensile Strength @5% Strain KN/m	7	14	17	21	28	32	35
Roll width	3.95 or 5.95 meters
Roll Length	50 meters

Plastic Geogrid Mesh Feature:

1. The flame retardant performance is good.
2. Friction is not easy to produce static electricity.
3. Easy to wash coal.
4. Corrosion resistance is strong, anti-aging.
5. Easy to construct and transport. The plastic net is relatively soft, it is not suitable for scratching workers in construction, and it is easy to curl and bind, and the mining grid is cut and light weight. Therefore, it is convenient for underground transportation, carrying and construction.
6. The bearing capacity of the vertical and horizontal directions is strong. Because the plastic net is biaxial stretch rather than woven, the creep variable of mesh hole is small, and the mesh size is uniform, which can effectively prevent the falling of coal fragments, protect the safety of underground workers and the safety of workers under the mine and the safety of mining car operation.

Application

1.It is suitable for subgrade reinforcement and Pavement Reinforcement of various highways, railways and airports.

2.It is suitable for foundation reinforcement of permanent bearing in large parking lot and wharf freight yard.

3.It is suitable for slope protection of railway and highway.

Suitable culvert reinforcement.

4.The false roof support engineering of underground mining face in coal mine.

5.Earth rock anchorage of underground civil engineering and traffic road engineering.
