Firm High Strength Reinforced Square Plastic Geogrid Mesh

Product Details:

Place of Origin:	Anping, China
Brand Name:	China
Certification:	ISO 9001
Model Number:	TGSG15-50

Payment & Shipping Terms:

Minimum Order Quantity:	1000 square meters
Price:	Negotiation
Packaging Details:	packing belt
Delivery Time:	5-8 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	40000M2 per week

Contact Now

Detailed Product Description

Material:	Polypropylene	Width:	3.9 Meters Or 5.9 Meters
Length:	50 Meters	Tensile Strength:	TGSG 25-25KN
Mesh HoLe:	32*32mm	Color:	Black, Gray, Green
Feature:	High Tension Resistance	Applications:	Convenient To Construct
Deliver Time:	About 10 Days After Order Was Confirmed	Project Solution:	Online Technical Support
High Light:	firm plastic geogrid mesh , high strength reinforced plastic geogrid mesh , square plastic geogrid mesh

New Product High Temperature Resistant Durable Plastic Geogrid Geogrid Fabric For Retaining Walls

Anping County Hengquan Metal Wire Mesh Products Co.,Ltd established in 2013, has specialized in the production and marketing of geogrids, geotextiles, geocells, geomembrane, chain link, welded wire mesh panel, hexagonal wire netting. The company now has a staff of 150 and 18 sets of professional high-tech equipment for geosynthetics and wire mesh production.

Biaxial Plastic Geogrid Introduction

Plastic two-way geogrid is made of high molecular polymer through extrusion, forming plate, punching process and then longitudinal and transverse tensile. The material has great tensile strength in both longitudinal and transverse directions. This kind of structure can also provide a more effective chain system for bearing and diffusing force in soil, which is suitable for large area permanent bearing foundation.

Biaxial Plastic Geogrid Specification

project	TGSG15-15	TGSG20-20	TGSG25-25	TGSG30-30	TGSG40-40	TGSG45-45	TGSG50-50
Longitudinal tensile yield force KN/m	15	20	25	30	40	45	50
Transverse tensile yield force KN/m	15	20	25	30	40	45	50
Tensile Strength @2% Strain KN/m	5	7	9	10.5	14	16	17.5
Tensile Strength @5% Strain KN/m	7	14	17	21	28	32	35
Roll width	3.95 or 5.95 meters
Roll Length	50 meters

Specification data

1, High tensile strength at both longitudinal and transverse direction.
2, High tension resistance,high plane torsion resistance modulus,good creep resistance and stable chemical nature.
3, High mechanic damage resistance and durability and large friction factor with sandy stone.
4, It can improve bearing force of foundation and increase diffusion angle.

Biaxial Plastic Geogrid Precautions:

1. Enhance the bearing capacity of road foundation and extend the duration of roads.
2. Prevent road surface from collapse, crack and being dirty.
3. Be convenient for construction, timesaving and cut down the cost of maintenance.
4. Prevent tunnel from crack occurring.
5. Further solidity slopes to proof water and soil from losses.
6. Reduce the surface thickness of the ground.
7. Consolidate the net for growing grass on the slopes so as to stabilization surrounding virescence.
8. Be used for artificial top net of mines instead of metal ones.

Plastic Geogrid Mesh Feature:

1. High tensile strength at both longitudinal and transverse direction.

2. High tension resistance,high plane torsion resistance modulus,good creep resistance and stable chemical nature.

3. High mechanic damage resistance and durability and large friction factor with sandy stone.

4. Improve bearing force of foundation and increase diffusion angle.

Workshop
