Gravel Grid Road Composite Biaxial Pp Geogrid Concrete Reinforcement

Product Details:

Place of Origin:	Anping, China
Brand Name:	China
Certification:	ISO 9001
Model Number:	TGSG15,TGSG20,TGSG25,TGSG30,TGSG35,TGSG40,TGSG45,TGSG50

Payment & Shipping Terms:

Minimum Order Quantity:	1000m2
Price:	Deliberation
Packaging Details:	packing belt
Delivery Time:	5-8 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	40000M2 per week

Contact Now

Detailed Product Description

Material:	Polypropylene	Width:	3.9 Meters Or 5.9 Meters
Length:	50 Meters	Tensile Strength:	TGSG 25-25KN
Mesh Hole:	32*32mm	Color:	Black, Gray, Green
Applications:	Convenient To Construct	Brand Name:	HENG QUAN
Place Of Origin:	Hebei, China	Package:	PP Woven Bags
High Light:	concrete reinforcement pp geogrid , pp geogrid biaxial , composite pp geogrid

Wholesale Gravel Grid Road Composite Pp Biaxial Plastic Concrete Reinforcement Geogrid Mesh

Biaxial Plastic Geogrid Introduction

1. PP Biaxial Plastic Geogrid is made from PP resin as its raw material, produced through extruding, punching, heating, longitudinal stretching, transverse stretching.

2. Performance: High tensile strength at both longitudinal & transverse dire.

Main type: 15-15, 20-20, 25-25, 30-30, 40-40, 50-50

Biaxial Plastic Geogrid Specification

project	TGSG15-15	TGSG20-20	TGSG25-25	TGSG30-30	TGSG40-40	TGSG45-45	TGSG50-50
Longitudinal tensile yield force KN/m	15	20	25	30	40	45	50
Transverse tensile yield force KN/m	15	20	25	30	40	45	50
Tensile Strength @2% Strain KN/m	5	7	9	10.5	14	16	17.5
Tensile Strength @5% Strain KN/m	7	14	17	21	28	32	35
Roll width	3.95 or 5.95 meters
Roll Length	50 meters
Feature	1.High tensile strength at both longitudinal and transverse direction. 2.High tension resistance,high plane torsion resistance modulus,good creep resistance and stable chemical nature. 3.High mechanic damage resistance and durability and large friction factor with sandy stone. 4.Improve bearing force of foundation and increase diffusion angle.

Biaxial Plastic Geogrid Precautions

1. The turning or braking of vehicles on the geotextile should be avoided as far as possible, especially when paving the asphalt surface course, any sharp turning or car killing sliding may bring up or damage the geotextile.
2. Construction under rainy, humid or cold weather conditions will affect the bonding strength and overlay effect of the coating.
3. Traffic must be closed during laying. Except for construction vehicles, other vehicles are allowed to pass through the geotextile only in case of emergency.
4. If there is slippage of paver when paving hot mix asphalt mixture, a small amount of stone chips can be sprinkled on the surface of tack coat oil.
Generally speaking, when we master the construction points of geotextile skillfully, we can make it play a greater economic benefit and make greater contribution to our urban construction.

Biaxial Plastic Geogrid Function

1. Increase road (ground) base bearing capacity and prolong the service life of road (ground).

2. Prevent road (ground) surface collapse or crack, ground is beautiful and tidy.

3. Construction is convenient, save time, effort, and shorten the construction period, reduce maintenance costs.

4. Prevent culvert crack.

5. Enhance soil, prevent soil erosion.

6. Reducing cushion thickness, saving the cost.

7. To support the stability of slope planting grass mat afforest environment.

8. Can replace the metal mesh, used in coal mine underground false roof net.
