Place of Origin: | China |
Brand Name: | HENGQUAN |
Certification: | CE /ISO9001 |
Model Number: | Z01 |
Minimum Order Quantity: | 5000 sqm |
---|---|
Price: | 0.46usd/㎡ |
Packaging Details: | PP Bags |
Delivery Time: | 5 days after 100% payment |
Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
Supply Ability: | 10,000 squre meters per week |
Coating: | Asphalt | Raw Material: | Glass Fiber Coated Bitumen |
---|---|---|---|
Width: | 2m-8m | Roll Length: | 50/100m |
Certificate: | CE /ISO9001 | Tensile Strength: | 20KN |
After-sale Service: | Onsite Installation, Onsite Inspection, Return And Replacem | Application: | Outdoor, Pavement Reinforcement, Road Pavement Reinforce |
Color: | Black | MESH SIZE: | 12.7*12.7mm/ 25.4*25.4mm/ 50.8*50.8mm |
High Light: | asphalt coating biaxial plastic geogrid,8m width biaxial plastic geogrid,asphalt coating pp biaxial geogrid |
20kn 30kn Plastic biaxial pp welded geogrid pp biaxial geogrid
Plastic Geogrid For Road Construction
ECL Biaxial PP Geogrid is an integrally formed structure, which especially designed for soil stabilization and reinforcement applications. ECL Biaxial Geogrid is manufactured from Polypropylene, from the process of extruding, punching,longitudinal stretching and transverse stretching. ECL Biaxial Geogrid features high tensile strength at both longitudinal and transverse directions. It makes soil reinforced with its excellent struture stability and strong mechanical interlock performance.
Flame retardant aditives
Light weight, high tensile strength, high modulus, low elongation and good
toughness. Corrosion resistance, no long-term creep, long life span.
Corrosion resistance,aging resistance
Good physical and chemical stability and good thermal stability.
Resistant to fatigue cracking, high-temperature track and low temperature shrinkage cracking.
Delaying and decreasing crack reflection.
Feature:
1 High tensile strength at low elongation.
2 Good creep property.
3 The chemical properties is steady.
4 The installation is convenient and fast.
1. Reinforcement of road beds of various highways, railways and airports.
2. Reinforcement of permanent bearing road beds of large parking area and dock goods yard.
3. Slope protections and culvert reinforcement of railway and highway.
4. Secondary reinforcement of soil slope after unidirectional tension geotechnical grid reinforcement and further reinforcement of soil slope sp as to avoid soil erosion.
5. Reinforcement of mile and gallery.
Tensile | Warp | ≥30 | ≥50 | ≥60 | ≥80 | ≥100 | ≥120 | ≥150 |
Strength | ||||||||
(KN) | Weft | ≥30 | ≥50 | ≥60 | ≥80 | ≥100 | ≥120 | ≥150 |
Elogation | Fiberglass | <4 % | 4 % | 4 % | 4 % | 4 % | 4 % | 4 % |
Polyester | <13% | 13% | 13% | 13% | 13% | 13% | 13% | |
Mesh size(mm) | 12.7×12.7 | 12.7×12.7 | 12.7×12.7 | 12.7×12.7 | 12.7×12.7 | 12.7×12.7 | 12.7×12.7 | |
25.4×25.4 | 25.4×25.4 | 25.4×25.4 | 25.4×25.4 | 25.4×25.4 | 25.4×25.4 | 25.4×25.4 | ||
42×42 | 42×42 | 42×42 | 42×42 | 42×42 | 42×42 | 42×42 | ||
50×50 | 50×50 | 50×50 | 50×50 | 50×50 | 50×50 | 50×50 | ||
Elastic Modulus | 76 | 76 | 76 | 76 | 76 | 76 | 76 | |
(Fiberglass) | ||||||||
Width(m) | 1~6 | 1~6 | 1~6 | 1~6 | 1~6 | 1~6 | 1~6 | |
Length(m) | 50~300 | 50~300 | 50~300 | 50~300 | 50~300 | 50~300 | 50~300 | |
Temperature | Fiberglass | -100~280 | -100~280 | -100~280 | -100~280 | -100~280 | -100~280 | -100~280 |
Resistant (°C) | Polyester | -100~280 | -100~280 | -100~280 | -100~280 | -100~280 | -100~280 | -100~280 |
Resin | Fiberglass | 18~20 | 18~20 | 18~20 | 18~20 | 18~20 | 18~20 | 18~20 |
Content (%) | polyester | ≤30% | ≤30% | ≤30% | ≤30% | ≤30% | ≤30% | ≤30% |
Q1. Can you do OEM?
A1. Yes.of course.We can produce the products as per your request.
If you can offer samples to us,it will be more convenient.
Q2. If I want to order a small quantity goods,can you do it?
A2. If the product you need we have stock available,that would be great,you can choose the instock goods.
but if not, don't worry, we can take your order with our other clients' order to be produced together.
But it needs to wait some time .
Q3. Can I get a sample from your company?Should I pay for the express fee?
A3. If you can accept our available sample,we can offer free sample to you.
If you want a customized sample,we can renegotiate the cost.
About the express fee,please offer a freight collected account and pay for the express fee by your side.
After confirming your order, the sample's freight cost will be deducted from your order's total cost.
Q4. How will you follow my order?
A4. When the goods are started to produce,we will take photos for the goods and send it to you.
If you find any production deficiencies,please contact us to correct it.
We will keep in touch with you in the whole production by e-mail or instant messaging, like Skype/Viber/WhatsApp, you can get the latest news about your order.
After the goods are finish,we will take photos for the goods and packing to you before shipping.
Package
Packed in woven geotextile and strength belt or PE film Or packed according to customers' requirements such as mark the company Logo (Export standard package).
Packaging size and container capacity vary according to product specifications.
