Name: Civil Engineering Construction Biaxial Plastic Geogrid For Reinforcement Road
Brand: HENGQUAN
SKU: Z01
Price: 0.46 USD
Availability: InStock
Rating: 4.8 (168 reviews)

Home Products Biaxial Plastic Geogrid

Civil Engineering Construction Biaxial Plastic Geogrid For Reinforcement Road

Product Details:

Place of Origin:	China
Brand Name:	HENGQUAN
Certification:	CE /ISO9001
Model Number:	Z01

Payment & Shipping Terms:

Minimum Order Quantity:	5000 sqm
Price:	0.46usd/㎡
Packaging Details:	PP Bags
Delivery Time:	5 days after 100% payment
Payment Terms:	T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability:	10,000 squre meters per week

Contact Now

Detailed Product Description

Coating:	Bitumen	Raw Material:	HDPE Plastic
Width:	2m-8m	Roll Length:	50-100m
Certificate:	CE/ISO9001 ISO14001	Tensile Strength:	25Kn/m--300Kn/m
After-sale Service:	Onsite Installation, Onsite Inspection, Return And Replacem	Application:	Road， Road Railway Construction
Color:	Black	MESH SIZE:	12.712.7mm/ 25.425.4mm/ 50.8*50.8mm
High Light:	civil engineering construction biaxial plastic geogrid , reinforcement road biaxial plastic geogrid , reinforcement road pp biaxial geogrid

PP Biaxial Geogrid Plastic Civil Engineering Construction Geogrids for Reinforcement Road

Geogrids
Geogrid is based on fiberglass woven cloth coated with modified bitumen or PVC, it was developed to address the problem of pavement cracking on highways, roads and runways, driven by a need to reduce cost for infrastructure maintenance and repair.
It is characterized by high tensile strength in axial and lateral directions, low stretch rate, alkali-resistance, low temperature- resistance, as well as convenience in construction and low price. It can be used on pitch pavement to prevent cracks and prolong pavement service life. It also can be used as a basal reinforcement material for hillsides, reservoirs, harbors,ports, water channels, seawalls, etc.

High tension resistance, high plane torsion resistance modulus, good creep resistance and stable chemical nature.

High mechanic damage resistance and durability and large friction factor with sandy stone.

Improve the bearing capacity of the roadbed and extend the service life of the roadbed.

INCREASE BEARING CAPACITY
Increase the bearing capacity of the road (foundation) and prolong the service life of the road (foundation).
CONVENIENT CONSTRUCTION
The construction is convenient, time-saving, labor-saving, shortening the construction period and reducing maintenance costs.
HIGH TENSILE STRENGTH
Support the stable green environment of the side slope grass planting net mat.
ENHANCED FORCE AREA
Prevent the road (ground) from collapse or cracks, and keep the ground beautiful and tidy.

Index Properties	Units	MD Values	XMD Values
Aperture Dimensions	mm (in)	38 (1.5)	38 (1.5)
Minimum Rib Thickness	mm (in)	1.1 (0.04)	0.8 (0.03)
Tensile Strength @ 2% Strain	kN/m (lb/ft)	6.5 (450)	6.5 (450)
Tensile Strength @ 5% Strain	kN/m (lb/ft)	13 (890)	13 (890)
Ultimate Tensile Strength	kN/m (lb/ft)	20 (1370)	20 (1370)
Structural Integrity
Junction Efficiency	%	93
Overall Flexural Rigidity	mg-cm	700,000
Aperture Stability	m-N/deg	0.45
Durability
Resistance to Installation Damage	%SC / %SW / %GP	95 / 93 / 90
Resistance to Long Term Degradation	%	100
Resistance to UV Degradation	%	100

Biaxial Fiberglass Geogrid
item	Specification
Type	EGA 30-30	EGA 50-50	EGA 80-80	EGA 100-100	EGA 120-120	EGA 150-150	EGA 200-200	EGA 300-300
Grid size (mm)	*12.512.5 or 25.425.4 or 50.850.8**
Latitude and longitude breaking strength ≥(KN/M)	30	50	80	100	120	150	200	300
Elongation at break in warp and weft ≤(%)	4

Packed in woven geotextile and strength belt or PE film Or packed according to customers' requirements such as mark the company Logo (Export standard package).

Packaging size and container capacity vary according to product specifications.

Civil Engineering Construction Biaxial Plastic Geogrid For Reinforcement Road 0
