Pond Polyethylene Geomembrane Rubber Epdm Liner

Pond Polyethylene Geomembrane Rubber Epdm Liner

  • Pond Polyethylene Geomembrane Rubber Epdm Liner
  • Pond Polyethylene Geomembrane Rubber Epdm Liner
  • Pond Polyethylene Geomembrane Rubber Epdm Liner
Pond Polyethylene Geomembrane Rubber Epdm Liner
Product Details:
Place of Origin: China
Brand Name: hengquan
Certification: CE/ISO9001
Model Number: zz-0228
Payment & Shipping Terms:
Minimum Order Quantity: 2000 Square Meter
Price: dollar+0.35usd---0.80usd+Square Meter
Packaging Details: Plastic bags
Delivery Time: 15days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000 Square Meter/Square Meters per Month
Contact Now
Detailed Product Description
Application: Pond, Landfill, Mining, Dam, Fish Pond, Road, Etc, Dam, Landfill Material: HDPE, LDPE, LLDPE
Surface: Smooth / Textured Length: 20m / 30m / 60m
Hs Code: 6807100000,56031410.00 Elongation At Break:: >600%
Type: Waterproof Membrane Life Expectancy: 10-30 Years
Sales Mode: Factory Sales Directly Project Solution Capability:: Graphic Design, Total Solution For Projects
High Light:

pond polyethylene geomembrane

,

rubber epdm liner polyethylene geomembrane

,

pond pe geomembrane

Geomembrane Rubber EPDM LinerApply To Pond Lining Fish Farms Swimming Pools Landfills





HDPE Geomembrane is made from high grade polyethylene raw material ,adding carbon black ,antioxidant, anti-aging and UV resistance component .It adopted the first class automatic production equipment and three-layer pressing technology.

Our HDPE geomembrane is made of 100% raw material hdpe which is imported from Middle East. After testing, the quality meets the ASTM standard completely.
0.5 or 0.75mm - use for pond liner
1.5mm - use for landfill
2.0mm - use for dam liner



Plastic HDPE Sheets
Good mechanical properties, high tear strength,
deformation and adaptable, puncture resistance,
anti-aging, anti-ultraviolet-resistant,
Anti oil and salt, pH, anti-corrosion,
high temperature-resistant, non-toxic,
long service life.
water,drainage, seepage, the good effect of moisture,
low cost, simple construction.






HDPE Geomembrane pond liner
1. Thickness: From 0.2mm to 3.0mm
2. Width: 1m to 8m, normal is 5.7m
3. Length: Normal is 50m/100m, or as per your request.
4. Standard: ASTM GM-13 standard (Virgin material)
5. Surface: Smooth or Textured
6. Color: Normal is black, other color can as per your request.



1) Environmental protection, sanitation (such as solid waste landfills, sewage treatment plants, power plants Chi-conditioning,
industrial, hospital solid waste, etc.)

2) Water (such as farming, rivers, lakes and reservoirs of the anti-dam, plugging, reinforcement of the canal seepage, etc.)

3) Municipal Engineering (subway, on the ground floor of the building, planted roof, the roof garden of anti-seepage, sewage pipes lining, etc.).

4) Landscape (man-made lake, river, reservoir, golf courses reservoirs of the substrate, slope protection, green lawn of the waterproof moisture, etc.).

5) Petrochemical (chemical plants, oil refineries, gas storage tanks of the anti-chemical reaction tanks, sedimentation tanks of the lining, etc.).

6) Mining (washing and pool heap leaching, the ash-field, dissolved, precipitation, the yard, the tailings seepage substrates, etc.) .

Properties
Test Method
Test Value
Thickness(mm)
ASTM D5199
0.50
0.75
1.0
1.25
1.5
2.0
2.5
Density (g/cm2)
ASTM D1505
0.94
Yield Strength(N/mm)
ASTM D6693
7
11
15
18
22
29
37
Break Strength(N/mm)
ASTM D6693
13
20
27
33
40
53
67
Yield Elongation %
Type IV
12
Break Elongation %
Type IV
700
Tear Resistance/N
ASTM D1004
62
93
125
156
187
249
311
Puncture Resistance/N
ASTM D4833
160
240
320
400
480
640
800
Stress Crack resistance/hr
ASTM D5397
(App.)
300
Carbon Black Content %
ASTM D1603
2.0-3.0
Carbon Black Dispersion
ASTM D5596
Carbon black dispersion(only near spherical agglomerates)for 10 different views 9 in categories 1 or 2 and 1 in category 3
Standard OIT/min
ASTM D3895
100
High Pressure OIT/min
ASTM D5885
400
Low tempreture impact brittle
property at -70°C
-
Pass
Permeability g·cm/(cm2)·Pa
-
≤1.0×10-13
Dimensional Stability/%
-
±2


Packaging: Strips packaging or Pallet Packaging
Lead time: Winthin 10-15 days after receiving the deposit payment
Producing capacity: Two 40FCL per week





Application

Pond Polyethylene Geomembrane Rubber Epdm Liner 0Pond Polyethylene Geomembrane Rubber Epdm Liner 1Pond Polyethylene Geomembrane Rubber Epdm Liner 2Pond Polyethylene Geomembrane Rubber Epdm Liner 3Pond Polyethylene Geomembrane Rubber Epdm Liner 4Pond Polyethylene Geomembrane Rubber Epdm Liner 5Pond Polyethylene Geomembrane Rubber Epdm Liner 6
