40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch

40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch

  • 40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch
  • 40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch
  • 40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch
40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch
Product Details:
Place of Origin: China
Brand Name: Hengquan
Certification: ISO 9001
Model Number: TGSG15,TGSG20,TGSG25,TGSG30,TGSG35,TGSG40,TGSG45,TGSG50
Payment & Shipping Terms:
Minimum Order Quantity: 1000m2
Price: Deliberation
Packaging Details: packing belt
Delivery Time: 5-8 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 40000 squre meters per week
Contact Now
Detailed Product Description
Product Name: Plastic Geogrid Width: 3.9 Meters Or 5.9 Meters
Roll Length: 30m To 50m Or Customized Tensile Strength: 25Kn/m--300Kn/m
Mesh Hole: 32*32mm Weight: 280g/m
Applications : Soft Foundation Reinforcement Raw Material: HDPE Plastic
High Light:

40kn biaxial plastic geogrid

,

two way stretch biaxial plastic geogrid

,

road reinforcement pp geogrid

40Kn Road Reinforcement Plastic Geo Grid With Two-way Stretch PP Biaxial Geogrid



About Hengquan

We have experience for more than 7 years. There are two product lines for geogrid and geocell. Factory work 24hours a day, we sold more than 100,000,000rmb last year(2020). Our customers are all over the world.



40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch 0



Brief Introduction of Geocell Confinement System

  The geogrid is used as a reinforcement for the foundation. It is backfilled with stone chips, concrete stones, and sand and gravel. After tamping, the occlusion and locking ability between the earth and the geogrid can be significantly increased, and the space between the soil bodies can be effectively restrained. The lateral displacement of the dispersed foundation and the shear force transmitted in all directions and the tensile mutation force. The introduction of high-strength anti-tensile geogrid reinforcement can prolong the service life of the foundation by at least 50 years. It has superior effects on cold resistance, high temperature resistance and chemical corrosion resistance.

Geogrid System Characteristic

  1. For roadbed reinforcement, the granular filler and the grid are interlocked to form a stable plane to prevent the filler from sinking and the vertical load is dispersed. Multi-layer reinforcement is used in areas with poor geographical conditions; 3. It is used for pavement reinforcement, so that the mesh and pavement materials are blended to effectively disperse and transmit loads to prevent pavement cracks; 4. Bear constant impact load; 5. Bear large alternating load; 6. Shorten Engineering construction period; 7. Construction can also be carried out under harsh environmental conditions; 8. Prevent pavement subsidence and cracks caused by grouting; 9. Reduce the amount of pavement materials; 10. Speed up construction.

Laying method

  When laying geogrids, the direction of force is required to be perpendicular to the axis direction of the roadbed to ensure smoothness, tension, no bulge, and overlap according to the design width. First, use U-shaped rivets to fix, the main force direction of the grille, try to ensure that the whole length has no joints, and control the overlap width to be more than 20 cm; The overlap width should be controlled at more than 10 cm; if two or more layers of grids are used, the upper and lower layers should be staggered. After the large area is laid, adjust the straightness; try to shorten the time when the grille is exposed
After filling a layer of soil, before rolling, the grid should be tensioned again to ensure that the grid is in a state of tension and stress.





Factory and Equipment:

40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch 1





Product inventory:

40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch 2

Application:

  In soft soil high fill engineering, laying geogrid in the middle of 30-50 cm gravel layer can form geogrid gravel cushion and give full play to the reinforcement role of excavated geogrid. On the one hand, the geogrid has strong shear resistance, which can effectively prevent the gravel from falling into the soft foundation, and promote the grid and gravel to be embedded closely to form a stable whole. On the other hand, the geogrid will form a horizontal plane in terms of drainage, which can be used as a drainage channel. After the subgrade is formed, it can effectively reduce the soil moisture content. Third, the geogrid is laid above the soft foundation, which will produce isolation effect,
It is not only convenient for construction, but also can restrain the lateral deformation of foundation and reduce uneven settlement. Fourth, increase the shear resistance of soil and change the physical and mechanical properties of soft foundation.





40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch 3

Specifications
Specifications: Biaxial geogrid
Item Properties Units MD Values1 XMD Values1
1 Aperture dimensions2 mm (in.) 25 (1.0) 33 (1.3)
2 Minimum rib thickness2 mm (in.) 0.76 (0.03) 0.76 (0.03)
3 Tensile strength at 2% strain3 kN/m (lb/ft.) 4.1 (280) 6.6 (450)
4 Tensile strength at 5% strain3 kN/m (lb/ft.) 8.5 (580) 13.4 (920)
5 Ultimate tensile strength3 kN/m (lb/ft.) 12.4 (850) 19.0 (1,300)
Structural Properties
6 Junction efficiency4 % MD Values1
7 Flexural stiffness5 mg-cm 250.000
8 Aperture stability6 m-N/deg 0.32
Durability
9 Resistance to installation damage7 %SC/%SW/%GP 95/93/90
10 Resistance to long term degradation8 % 100
11 Resistance to UV degradation9 % 100
Dimensions
12 Roll sizes m (ft.) 3.0 × 75.0 (9.8 × 246); 4.0 × 75.0 (13.1 × 246)
Certifications
40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch 4
40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch 5
40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch 6
40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch 7
Our Company
40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch 8
40kn Biaxial Plastic Geogrid Road Reinforcement With Two Way Stretch 9


Year of Registration: 2014

Place of Registration: China

Registrated Capital: CNY105,000,000.00

Briture Co., Ltd

was approved by Chinese Bureau of Commerce
