| Place of Origin: | China |
| Brand Name: | Hengquan |
| Certification: | ISO 9001 |
| Model Number: | 100 - 800 G/㎡ |
| Minimum Order Quantity: | 1000m2 |
|---|---|
| Price: | Deliberation |
| Packaging Details: | packing belt |
| Delivery Time: | 5-8 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 40000M2 per week |
| Material: | Polyester | Thickness: | 0.9 - 4.0 Mm |
|---|---|---|---|
| Weight: | 100 - 600 G | Color: | Black , White , Grey, Green |
| Width: | 1-5.95 Meters | Length: | 50 Or 100 Meters |
| Application: | Road Stabilization Applications | ||
| High Light: | 2.0mm Needle Punched Geotextile,Tear Resistance Needle Punched Geotextile,0.6KN Non Woven Landscape Fabric |
||
UV-Stabilized Composited Road Stabilization Applications High Strength Needle Punched Geotextile Fabric
Needle Punched Geotextile Fabric Description
Nonwoven fabrics are made by extruding continuous filaments of polypropylene which are then cut, opened, laid into a web, needle-punched, heat-set and rolled into the finished product. These geotextiles are approved by many local, state and federal agencies including the Federal Highway Administration, U.S. Army Corps of engineers, the environmental Protection Agency and AASHTO.
Needle Punched Geotextile Fabric Specification
| Gram weight | Thickness(mm) | Breaking strength(kn/m) | CBR burst strength(KN) | Elongation at break(% | Tear Strength(KN) | Sieve size O99(O35)mm |
| 100 | 0.9 | 2.5 | 0.3 | 25-100 | 0.08 | 0.07-2.0 |
| 150 | 1.3 | 4.5 | 0.6 | 25-100 | 0.12 | 0.07-2.0 |
| 200 | 1.7 | 6.5 | 0.9 | 25-100 | 0.16 | 0.07-2.0 |
| 250 | 2.1 | 8.0 | 1.2 | 25-100 | 0.20 | 0.07-2.0 |
| 300 | 2.4 | 9.5 | 1.5 | 25-100 | 0.24 | 0.07-2.0 |
| 350 | 2.7 | 11.0 | 1.8 | 25-100 | 0.28 | 0.07-2.0 |
| 400 | 3.0 | 12.5 | 2.1 | 25-100 | 0.33 | 0.07-2.0 |
| 450 | 3.3 | 14.0 | 2.4 | 25-100 | 0.38 | 0.07-2.0 |
| 500 | 3.6 | 16.0 | 2.7 | 25-100 | 0.42 | 0.07-2.0 |
| 600 | 4.1 | 19.0 | 3.2 | 25-100 | 0.46 | 0.07-2.0 |
| 800 | 5.0 | 25.0 | 4.0 | 25-100 | 0.60 | 0.07-2.0 |
Needle Punched Geotextile Fabric Features
Excellent tear resistance
Excellent puncture resistance
Increases performance life of roadways
Offers filtration efficiencies
These fabrics are designed to filter soil particles from drainage systems and stabilize roadways to increase performance life. Nonwovens are ideal for a variety of civil engineering applications including:
Subsurface Drainage
Roadway Separation
Railroad Stabilization
Hard Armor Underlayment
Landfill Leachate Collection
Underground Detention/Retention System
Nonwoven Fabrics (Spunbonded)
