Anping County Hengquan Metal Wire Mesh Products Co.,Ltd
geogrids, geotextiles, geocells, geomembrane, chain link fence , welded wire mesh panel, hexagonal wire netting
 |
| Place of Origin: | China |
| Brand Name: | Hengquan |
| Certification: | ISO 9001 |
| Model Number: | Cell Heighth: 50-300mm |
| Minimum Order Quantity: | 1000m2 |
|---|---|
| Price: | Deliberation |
| Packaging Details: | packing belt |
| Delivery Time: | 5-8 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 40000M2 per week |
| Material: | High Density Polyethylene | Cell Height: | 50-300mm |
|---|---|---|---|
| Weld Spacing: | 330mm To 1600mm | Seam Peel Strength: | 1000N, 1100N,1200N,1420N |
| Thickness: | 1.0-1.6mm | Color: | Black Green Gray |
| Used: | Embankment Restoration | Feature: | Eco-Friendly |
| High Light: | 1100N Cellular Confinement System,Reinforce Roadbed Cellular Confinement System,1100N Geocell Erosion Control |
||
Reinforce Roadbed Easier To Install High Strength Cellular Confinement System
Cellular Confinement System Information
Cellular Confinement System(CCS)--also known as geocell, it is a kind of three-dimensional network structure shaped by high-strength HDPE (high density polyethylene) sheets through ultrasonic welding of high strength. The depth of the geocells as well as the size of each cellular unit can vary as per design requirements. The surface of geocells are smooth or textured, the textured geocells increase soil-geocell wall friction. Geocells can be perforated or non-perforated.
Cellular Confinement System Specification
1. Cell depth: 50mm,100mm,150mm,200mm,250mm,300mm
2. Welding distance: 330mm~1600mm
3. Thickness: 1.0mm,1.2mm(smooth), 1.5mm,1.8mm(textured)
4. Appearance/surface: smooth/textured
| Item | Main Specification |
| Weld Spacing | 330mm to 1600mm |
| Cell Height | 50mm to 300mm |
| Seam Peel Strength | 1000N, 1100N,1200N,1420N |
| Color | Black, Green, Sand, pray |
| Surface | Smooth/Textured/Perforated |
Cellular Confinement System Feature
1,Eco-Friendly
2,Inexpensive
3,Permanent Solution
4,Low Maintenance
5,Cells can be filled with soil and planted with vegetation or filled with aggregates
6,Easier to install than a retaining wall
We can help you with geocell design support. Take advantage of our 35-year geocell technology experience and let us perform a free evaluation for your GEOWEB® project. Our recommendations will deliver a structurally-sound, cost-effective solution based on three-decades of accredited research and testing data.
Contact Person: Mrs. ruby
Tel: +86-13623182253
Fax: 86-318-7990083
