High Density Polyethylene Smooth Geocell For Road Construction

Common Application Smooth Perforated High Density Polyethylene Cellular Confinement System

Cellular Confinement System information

Cellular Confinement System(CCS)--also known as geocell, it is a kind of three-dimensional network structure shaped by high-strength HDPE (high density polyethylene) sheets through ultrasonic welding of high strength. The depth of the geocells as well as the size of each cellular unit can vary as per design requirements. The surface of geocells are smooth or textured, the textured geocells increase soil-geocell wall friction. Geocells can be perforated or non-perforated. If the depth of geocell is over 10cm, the geocell can be perforated, the geocell wall is punctured to assist in immediate dissipation of developed porewater pressures due to increased stresses within the infill of the individual cells.

Cellular Confinement System Specification

1. Cell depth: 50mm,100mm,150mm,200mm,250mm,300mm
2. Welding distance: 330mm~1600mm
3. Thickness: 1.0mm,1.2mm(smooth), 1.5mm,1.8mm(textured)
4. Appearance/surface: smooth/textured

Cellular Confinement System Feature

1)Local material can be used during construction, reduce the construction cost, easy to be transported after folding together.

2)Geocells are easy to install and do not require skilled labour.They can be installed in any weather condition.

 3)The in-fill has essentially to be non-cohesion material,however the material could be recycled material.
